V3 RED Submersible Pump (SKU - RP3/0510S)

Actual Price ₹6200.00

M.R.P. : ₹5000.00 -78%

Delivery FREE

V3 RED Submersible Pump 0.5 HP X 10 Stg 1 Ø

Phase: Single Phase

Rotor: Copper Rotor

Winding: Copper Winding

₹5000.00 Saving

Choose Option

Buy without exchange

Buy with exchange

Add To Cart

Add Accessories

Shop online for new arrivals and get free shipping!

1 year Warranty

(Ex.ShowRoom)

Safe Delivery

Safe delivery to your doorstep

Excellent Quality

Approved Performance Details

Easy-Safe Payment

Pay with ease and safety

Detail
Performance

We offer superior quality of V-4 Submersible Pumps, which are cast from high grade stainless steel. These pumps are light and have a compact built. We use latest technology with innovative designs in manufacturing these pumps. The outstanding quality and unbeatable performance...

We offer superior quality V-4 Submersible Pumps which are cast from high grade stainless steel. These pumps are light and have a compact built. We use the latest technology with innovative designs in manufacturing these pumps. The outstanding quality and unbeatable performance of our product has made it our clients' favourite choice. These pumps are easy to operate, consume less energy, maintenance free, and highly efficient and on top of these, we are offering these pumps at a very attractive price. our pumps have made these extensively popular. These pumps are easy to operate, consume less energy, maintenance free and highly efficient. This pump set is examined in terms of quality in order to supply an excellent range. Offered pump set is developed using the finest quality components and sophisticated technology. Our entire range of pump set is highly acknowledged in the market for its high quality & consistent performance.

MOC

Power Range (for 1 ph) : 0.5 HP to 3.0 HP
Power Range (for 3ph) : 1.0 HP to 7.5 HP
Power Supply (for 1 ph) : 230 Volts (+6% / -15%), 1-ph, AC, 50 Hz) ± 3%), Power Supply (for 3ph) : 415 Volts (+6% /-15%), 3-ph, AC, 50 Hz) ± 3%)
Total Head : Up to 400 mtrs
Flow Rate : Up to 525 1pm
Pipe Size : 25,32, 40, 50 & 65 mm
Pole/ Syn. Speed : 2 Pole /2800 rpm
Motor Detail : Wet Type, CAT - B, Duty - S1, Submersible Pumpset
Max. Water Temperature : 33 °C
Suitable Bore Size : 100 mm
Pumps are available in Multistage, highly efficient Radial Flow design
Motor & Pump Diameter 86 mm

Specification

Motor Body : Stainless Steel
Rotor : Copper Rotor
Windings : Copper wire with class F insulation
Impeller : High quality abrasion resistant Noryl / Virgin Steel & dynamically balanced.
Bowl : High grade Noryl / Virgin
Shaft : Stainless Steel of adequate Diameter to ensure rigidity
carbon + SS : Contact bearing
Wear Rings : High quality abrasion resistant P.U. / Rubber
Seal : Mechanical Seal
